Experiment details for cacna1d



Cloning and characterization of voltage-gated calcium channel alpha1 subunits in Xenopus laevis during development.

Good quality Poor quality
Gene Clone Species Stages Anatomy
cacna1d.L laevis NF stage 35 and 36 to NF stage 37 and 38 facial nerve

Display additional annotations [+]
  Figure 4. Midbrain histological analysis of voltage-gated calcium channel (VGCC) alpha 1 subunit expression in stages 35-37 (swimming tadpole) X. laevis using whole-mount in situ hybridization. A-J: Transverse 18- mu m sections within the midbrain region of the anterior-posterior axis, with dorsal to the top. A,B: CaV1.2 expression. C: CaV1.3 expression. D,E: CaV2.1 expression. F,G: CaV2.2 expression. H,I: CaV3.1 expression. J: CaV3.2 expression. Arrowheads indicate regions of expression. mb, midbrain; e, eye; ht, heart; V, cranial ganglion V, trigeminal ganglion; VII, cranial ganglion VII, geniculate (facialis) ganglion. Scale bar = 0.25 mm.
