???displayArticle.abstract???
The VEGF receptor, FLK1, is essential for differentiation of the endothelial lineage and for embryonic vascular development. Using comparative genomics, we have identified conserved ETS and Krüppel-like factor (KLF) binding sites within the Flk1 enhancer. In transgenic studies, mutation of either site results in dramatic reduction of Flk1 reporter expression. Overexpression of KLF2 or the ETS transcription factor ERG is sufficient to induce ectopic Flk1 expression in the Xenopus embryo. Inhibition of KLF2 function in the Xenopus embryo results in a dramatic reduction in Flk1 transcript levels. Furthermore, we show that KLF2 and ERG associate in a physical complex and that the two proteins synergistically activate transcription of Flk1. Since the ETS and KLF protein families have independently been recognized as important regulators of endothelial gene expression, cooperation between the two families has broad implications for gene regulation during development, normal physiology and vascular disease.
Fig. 3. Inhibition of KLF2 function results in reduced Flk1 expression in the Xenopus embryo. (A-C) Whole-mount in situ hybridization analysis of Flk1, Erg and Klf2 expression in Xenopus embryos (stage 34, lateral view). For each gene, expression is observed in the endothelial cells of the major developing vessels, including the posterior cardinal vein (PCV), intersomitic vessels (IS), aortic arches (AA) and in the forming plexus on the flank of the embryo (PL). (D,E) Klf2 MO effectively blocks translation of a control Klf2 transcript. (D) Bright-field and fluorescent images of embryos injected with a control transcript in which the 5′ UTR of Klf2 was fused to the coding sequences of GFP (Klf2-GFP). (E) Bright-field and fluorescent images of embryos injected with Klf2-GFP transcript plus Klf2 MO (25 ng). Note that GFP reporter fluorescence is greatly inhibited by Klf2 MO treatment. (F) Embryo injected with 50 ng of a control MO and assayed for expression of Flk1 transcripts. The inset is a higher magnification view, centered on the developing posterior cardinal vein. (G,H) Two different embryos injected with 50 ng of Klf2 MO and assayed for expression of Flk1. Klf2 MO-injected embryos show a dramatic reduction of Flk1 expression. (I) Embryo injected with 500 pg of GFP mRNA and assayed for Flk1 transcripts. (J,K) Two different embryos injected with 250 pg of mRNA encoding a dominant-repressor form of KLF2 (DR-KLF2) and assayed for Flk1 transcripts. Embryos expressing the DR-KLF2 construction show a dramatic reduction of Flk1 transcripts. (L) qRT-PCR analysis reveals significant reduction in Flk1 transcript levels in Klf2 MO-treated embryos. Results shown are the average of three separate embryos for each MO treatment. (M-M′) Klf2 MO treatment eliminates vascular tubes. Histological section through a stage 42 embryo injected with Klf2 MO. Somites (s) and notochord (nc) are indicated. Scale bar: 100 μm. Injected side is to the right (arrowhead). M′ and M′ show enlargements of the region of the posterior cardinal vein on the untreated and treated sides, respectively. Although the pronephric duct (pnd) is visible on both sides, no tube corresponding to the posterior cardinal vein (pcv) is visible on the treated side.
Fig. 7. KLF2 is necessary and sufficient for expression of other vascular marker genes. In situ hybridization analysis of X-msr and VE-cadherin expression in injected Xenopus embryos (stage 34, lateral view). (A-D) Klf2 MO blocks expression of the vascular markers X-msr and VE-cadherin, as compared with control MO-injected embryos. The insets are higher magnification views, centered on the developing posterior cardinal vein. (E-H) Injection of Klf2 mRNA (500 pg) induces ectopic expression of X-msr and VE-cadherin (arrows).
Klf2 MO blocks expression of the vascular markers X-msr and VE-cadherin, as compared with control MO-injected embryos. The insets are higher magnification views, centered on the developing posterior cardinal vein.
The developing circulatory system in a Xenopus laevis embryo, visualized through gene expression of aplnr (apelin receptor). The inset is a higher magnification view, centered on the developing posterior cardinal vein, and branching intersomitic vessels.
Klf2 MO blocks expression of the vascular markers X-msr and VE-cadherin, as compared with control MO-injected embryos. The insets are higher magnification views, centered on the developing posterior cardinal vein.
Atkins,
Role of Krüppel-like transcription factors in endothelial biology.
2007, Pubmed
Atkins,
Role of Krüppel-like transcription factors in endothelial biology.
2007,
Pubmed
Baltzinger,
Xl erg: expression pattern and overexpression during development plead for a role in endothelial cell differentiation.
1999,
Pubmed
,
Xenbase
Bhattacharya,
Inhibition of vascular permeability factor/vascular endothelial growth factor-mediated angiogenesis by the Kruppel-like factor KLF2.
2005,
Pubmed
Bieker,
Krüppel-like factors: three fingers in many pies.
2001,
Pubmed
Birdsey,
Transcription factor Erg regulates angiogenesis and endothelial apoptosis through VE-cadherin.
2008,
Pubmed
Botella,
Transcriptional activation of endoglin and transforming growth factor-beta signaling components by cooperative interaction between Sp1 and KLF6: their potential role in the response to vascular injury.
2002,
Pubmed
Bouwmeester,
Cerberus is a head-inducing secreted factor expressed in the anterior endoderm of Spemann's organizer.
1996,
Pubmed
,
Xenbase
Carmeliet,
Abnormal blood vessel development and lethality in embryos lacking a single VEGF allele.
1996,
Pubmed
Cleaver,
Neovascularization of the Xenopus embryo.
1997,
Pubmed
,
Xenbase
Conkright,
Lung Krüppel-like factor contains an autoinhibitory domain that regulates its transcriptional activation by binding WWP1, an E3 ubiquitin ligase.
2001,
Pubmed
Dang,
The biology of the mammalian Krüppel-like family of transcription factors.
2000,
Pubmed
Dejana,
Foxs and Ets in the transcriptional regulation of endothelial cell differentiation and angiogenesis.
2007,
Pubmed
Dekker,
KLF2 provokes a gene expression pattern that establishes functional quiescent differentiation of the endothelium.
2006,
Pubmed
Dekker,
Endothelial KLF2 links local arterial shear stress levels to the expression of vascular tone-regulating genes.
2005,
Pubmed
Devic,
Expression of a new G protein-coupled receptor X-msr is associated with an endothelial lineage in Xenopus laevis.
1996,
Pubmed
,
Xenbase
Doherty,
A flk-1 promoter/enhancer reporter transgenic Xenopus laevis generated using the Sleeping Beauty transposon system: an in vivo model for vascular studies.
2007,
Pubmed
,
Xenbase
Elvert,
Cooperative interaction of hypoxia-inducible factor-2alpha (HIF-2alpha ) and Ets-1 in the transcriptional activation of vascular endothelial growth factor receptor-2 (Flk-1).
2003,
Pubmed
Ferrara,
Heterozygous embryonic lethality induced by targeted inactivation of the VEGF gene.
1996,
Pubmed
Garriock,
Wnt11-R, a protein closely related to mammalian Wnt11, is required for heart morphogenesis in Xenopus.
2005,
Pubmed
,
Xenbase
Gory,
The vascular endothelial-cadherin promoter directs endothelial-specific expression in transgenic mice.
1999,
Pubmed
Harland,
In situ hybridization: an improved whole-mount method for Xenopus embryos.
1991,
Pubmed
,
Xenbase
Hasegawa,
Transcriptional regulation of human angiopoietin-2 by transcription factor Ets-1.
2004,
Pubmed
Jiang,
A core Klf circuitry regulates self-renewal of embryonic stem cells.
2008,
Pubmed
Kaczynski,
Sp1- and Krüppel-like transcription factors.
2003,
Pubmed
Kappel,
Identification of vascular endothelial growth factor (VEGF) receptor-2 (Flk-1) promoter/enhancer sequences sufficient for angioblast and endothelial cell-specific transcription in transgenic mice.
1999,
Pubmed
Kappel,
Role of SCL/Tal-1, GATA, and ets transcription factor binding sites for the regulation of flk-1 expression during murine vascular development.
2000,
Pubmed
Kojima,
Transcriptional activation of urokinase by the Krüppel-like factor Zf9/COPEB activates latent TGF-beta1 in vascular endothelial cells.
2000,
Pubmed
Kroll,
Transgenic Xenopus embryos from sperm nuclear transplantations reveal FGF signaling requirements during gastrulation.
1996,
Pubmed
,
Xenbase
Kuo,
The LKLF transcription factor is required for normal tunica media formation and blood vessel stabilization during murine embryogenesis.
1997,
Pubmed
Lee,
Klf2 is an essential regulator of vascular hemodynamic forces in vivo.
2006,
Pubmed
Lee,
ER71 acts downstream of BMP, Notch, and Wnt signaling in blood and vessel progenitor specification.
2008,
Pubmed
Lelièvre,
The Ets family contains transcriptional activators and repressors involved in angiogenesis.
2001,
Pubmed
Li,
Regulation of Ets function by protein - protein interactions.
2000,
Pubmed
Lin,
Kruppel-like factor 2 (KLF2) regulates endothelial thrombotic function.
2005,
Pubmed
Matsumoto,
Developmental regulation of yolk sac hematopoiesis by Kruppel-like factor 6.
2006,
Pubmed
Meadows,
The myocardin-related transcription factor, MASTR, cooperates with MyoD to activate skeletal muscle gene expression.
2008,
Pubmed
,
Xenbase
Meyer,
Xl-fli, the Xenopus homologue of the fli-1 gene, is expressed during embryogenesis in a restricted pattern evocative of neural crest cell distribution.
1993,
Pubmed
,
Xenbase
Meyer,
Ets-1 and Ets-2 proto-oncogenes exhibit differential and restricted expression patterns during Xenopus laevis oogenesis and embryogenesis.
1997,
Pubmed
,
Xenbase
Meyer,
Whole-mount in situ hybridization reveals the expression of the Xl-Fli gene in several lineages of migrating cells in Xenopus embryos.
1995,
Pubmed
,
Xenbase
Oates,
The zebrafish klf gene family.
2001,
Pubmed
Oikawa,
Molecular biology of the Ets family of transcription factors.
2003,
Pubmed
Parmar,
Integration of flow-dependent endothelial phenotypes by Kruppel-like factor 2.
2006,
Pubmed
Pham,
Combinatorial function of ETS transcription factors in the developing vasculature.
2007,
Pubmed
Schlaeger,
Uniform vascular-endothelial-cell-specific gene expression in both embryonic and adult transgenic mice.
1997,
Pubmed
Schwachtgen,
Ets transcription factors bind and transactivate the core promoter of the von Willebrand factor gene.
1997,
Pubmed
Segre,
Klf4 is a transcription factor required for establishing the barrier function of the skin.
1999,
Pubmed
Shalaby,
Failure of blood-island formation and vasculogenesis in Flk-1-deficient mice.
1995,
Pubmed
Sharrocks,
The ETS-domain transcription factor family.
2001,
Pubmed
Sparrow,
A simplified method of generating transgenic Xenopus.
2000,
Pubmed
,
Xenbase
Stiegler,
Characterization of Xenopus laevis cDNA clones of the c-ets-1 proto-oncogene.
1990,
Pubmed
,
Xenbase
Stiegler,
The c-ets-1 proto-oncogenes in Xenopus laevis: expression during oogenesis and embryogenesis.
1993,
Pubmed
,
Xenbase
Turner,
Basic Krüppel-like factor functions within a network of interacting haematopoietic transcription factors.
1999,
Pubmed
Wakiya,
A cAMP response element and an Ets motif are involved in the transcriptional regulation of flt-1 tyrosine kinase (vascular endothelial growth factor receptor 1) gene.
1996,
Pubmed
Yet,
Human EZF, a Krüppel-like zinc finger protein, is expressed in vascular endothelial cells and contains transcriptional activation and repression domains.
1998,
Pubmed
