???displayArticle.abstract???
Photoreceptors are among the most metabolically active cells in the body, relying on both oxidative phosphorylation and glycolysis to satisfy their high energy needs. Local glycolysis is thought to be particularly crucial in supporting the function of the photoreceptor's light-sensitive outer segment compartment, which is devoid of mitochondria. Accordingly, it has been commonly accepted that the facilitative glucose transporter Glut1 responsible for glucose entry into photoreceptors is localized in part to the outer segment plasma membrane. However, we now demonstrate that Glut1 is entirely absent from the rod outer segment and is actively excluded from this compartment by targeting information present in its cytosolic C-terminal tail. Our data indicate that glucose metabolized in the outer segment must first enter through other parts of the photoreceptor cell. Consequently, the entire energy supply of the outer segment is dependent on diffusion of energy-rich substrates through the thin connecting cilium that links this compartment to the rest of the cell.
Fig.2. Glut1 immunolocalization in amphibian retina. (A) Western blot analysis of retinal extracts from mouse (lane 1) and Xenopus (lane 2), probed with anti-human Glut1 polyclonal antibody. The Xenopus isoform was not recognized. (B) The polyclonal antibody raised against Xenopus Glut1 specifically recognized this protein in an immunoblot of Xenopus retinal extract. (C) A section of Xenopus retina immunostained for Glut1 (green). Nuclei were counter-stained with Hoechst 33342 (blue). To the left is a schematic of a frog rod photoreceptor with an overlying RPE cell, illustrating the relative positions of individual subcellular compartments. Abbreviations are the same as in Fig. 1. Scale bar: 20 μm. (D–I) Xenopus retinal cryosections stained for Glut1 (green) and Na+/K+-ATPase (NKA, red; D–F) or phalloidin (red; G–I). Glut1 localized to the RPE and its microvilli, and to the rod photoreceptor plasma membrane in the synaptic, nuclear and inner segment layers. Labeling of the Na+/K+-ATPase (D–F) was used as a marker for the photoreceptor inner segment plasma membrane and calycal processes (arrowheads). Labeling of F-actin with phalloidin (G–I) was used as a marker for the RPE microvilli, in addition to the photoreceptor calycal processes. (J–L) Staining of two isolated rod photoreceptor fragments revealed Glut1 (green) on inner segment (IS) membranes and calycal processes (arrowheads) but not along the plasma membrane of outer segments (OS) marked by wheat germ agglutinin (WGA, red). Scale bars: 10 μm (D–L).
Fig.3. Immunogold analysis of Glut1 in Xenopus retina sections. Longitudinal sections (A,B) and cross-sections (C,D) through Xenopus retina were processed for immunogold analysis. Gold particles (representatives marked by red arrowheads) were abundant on the fingerlike RPE microvilli (A) and their cross-sections (C). Rare, nonspecific particles (green arrowheads) were occasionally found within the rod outer segments, with no preference for the lateral plasma membrane; they were found at similar frequencies in control sections incubated with rabbit IgG control (B,D). (E) Gold particle labeling densities (particles per μm2 of membrane) were calculated for the outer segments and microvilli in both Glut1-stained and control sections. The mean labeling density for each type of structure in ten separate images is plotted with error bars representing 95% confidence intervals. MV, microvilli; OS, outer segment; ROS, rod outer segment. Scale bars: 200 nm.
Fig.4. GFP-tagged Glut1 is actively excluded from rod outer segments of transgenic Xenopus tadpoles. (A,B) GFP-tagged Glut1 was expressed in transgenic tadpole rods and localized to the plasma membrane of the synaptic terminal, nuclear region and inner segment, including the calycal processes (arrowheads). The outer segments extend well beyond the GFP signal in the calycal processes (B). (C) GFP-tagged Glut1 mutant lacking its 38-residue C-terminal tail (GFP–Glut1δ38) displayed prominent outer segment localization in tadpole rods. OS, outer segment; IS, inner segment; N, nucleus; ST, synaptic terminal. Scale bars: 10 μm.
Acosta,
Early markers of retinal degeneration in rd/rd mice.
2005, Pubmed
Acosta,
Early markers of retinal degeneration in rd/rd mice.
2005,
Pubmed
Amaya,
A method for generating transgenic frog embryos.
1999,
Pubmed
,
Xenbase
Aslanukov,
RanBP2 modulates Cox11 and hexokinase I activities and haploinsufficiency of RanBP2 causes deficits in glucose metabolism.
2006,
Pubmed
Baker,
The outer segment serves as a default destination for the trafficking of membrane proteins in photoreceptors.
2008,
Pubmed
,
Xenbase
Bunn,
Protein interactions with the glucose transporter binding protein GLUT1CBP that provide a link between GLUT1 and the cytoskeleton.
1999,
Pubmed
Chih,
Do active cerebral neurons really use lactate rather than glucose?
2001,
Pubmed
COHEN,
Glucose catabolism of rabbit retina before and after development of visual function.
1960,
Pubmed
Cook,
The cGMP-gated channel of bovine rod photoreceptors is localized exclusively in the plasma membrane.
1989,
Pubmed
Dowling,
THE FINE STRUCTURE OF THE PIGMENT EPITHELIUM IN THE ALBINO RAT.
1962,
Pubmed
Elliott,
Differential distribution of proteins and lipids in detergent-resistant and detergent-soluble domains in rod outer segment plasma membranes and disks.
2008,
Pubmed
Futterman,
Metabolism of glucose and reduction of retinaldehyde in retinal photoreceptors.
1970,
Pubmed
Giorgino,
The sentrin-conjugating enzyme mUbc9 interacts with GLUT4 and GLUT1 glucose transporters and regulates transporter levels in skeletal muscle cells.
2000,
Pubmed
Hsu,
Glycolytic enzymes and a GLUT-1 glucose transporter in the outer segments of rod and cone photoreceptor cells.
1991,
Pubmed
Hsu,
Glucose metabolism in photoreceptor outer segments. Its role in phototransduction and in NADPH-requiring reactions.
1994,
Pubmed
Insinna,
Intraflagellar transport and the sensory outer segment of vertebrate photoreceptors.
2008,
Pubmed
Kroll,
Transgenic Xenopus embryos from sperm nuclear transplantations reveal FGF signaling requirements during gastrulation.
1996,
Pubmed
,
Xenbase
Kumagai,
GLUT1 glucose transporter expression in the diabetic and nondiabetic human eye.
1994,
Pubmed
Kwok,
Proteomics of photoreceptor outer segments identifies a subset of SNARE and Rab proteins implicated in membrane vesicle trafficking and fusion.
2008,
Pubmed
Linton,
Flow of energy in the outer retina in darkness and in light.
2010,
Pubmed
Liu,
The proteome of the mouse photoreceptor sensory cilium complex.
2007,
Pubmed
Lopez-Escalera,
Glycolysis and glucose uptake in intact outer segments isolated from bovine retinal rods.
1991,
Pubmed
LOWRY,
Quantitative histochemistry of retina. II. Enzymes of glucose metabolism.
1961,
Pubmed
Mantych,
Characterization of glucose transporter isoforms in the adult and developing human eye.
1993,
Pubmed
Mathupala,
Hexokinase-2 bound to mitochondria: cancer's stygian link to the "Warburg Effect" and a pivotal target for effective therapy.
2009,
Pubmed
McConnell,
Evidence for glycolysis in bovine retinal microsomes and photoreceptor outer segments.
1969,
Pubmed
Nihira,
Primate rod and cone photoreceptors may differ in glucose accessibility.
1995,
Pubmed
Okawa,
ATP consumption by mammalian rod photoreceptors in darkness and in light.
2008,
Pubmed
Poitry-Yamate,
Lactate released by Müller glial cells is metabolized by photoreceptors from mammalian retina.
1995,
Pubmed
Punzo,
Stimulation of the insulin/mTOR pathway delays cone death in a mouse model of retinitis pigmentosa.
2009,
Pubmed
Rajala,
G-protein-coupled receptor rhodopsin regulates the phosphorylation of retinal insulin receptor.
2007,
Pubmed
Reid,
Identification of the sodium-calcium exchanger as the major ricin-binding glycoprotein of bovine rod outer segments and its localization to the plasma membrane.
1990,
Pubmed
Spencer,
Distribution of membrane proteins in mechanically dissociated retinal rods.
1988,
Pubmed
Stahl,
Immunocytochemical localization of Na+,K+ adenosine triphosphatase in the rat retina.
1984,
Pubmed
Takata,
Ultracytochemical localization of the erythrocyte/HepG2-type glucose transporter (GLUT1) in cells of the blood-retinal barrier in the rat.
1992,
Pubmed
Takata,
Erythrocyte/HepG2-type glucose transporter is concentrated in cells of blood-tissue barriers.
1990,
Pubmed
Umino,
Hypoglycemia leads to age-related loss of vision.
2006,
Pubmed
Verhey,
Identification of the carboxy terminus as important for the isoform-specific subcellular targeting of glucose transporter proteins.
1993,
Pubmed
Wieman,
An essential role for the Glut1 PDZ-binding motif in growth factor regulation of Glut1 degradation and trafficking.
2009,
Pubmed
Wilkin,
Localization of hexokinase in neural tissue: light microscopic studies with immunofluorescence and histochemical procedures.
1977,
Pubmed
Winkler,
Glycolytic and oxidative metabolism in relation to retinal function.
1981,
Pubmed
Winkler,
Cultured retinal neuronal cells and Müller cells both show net production of lactate.
2004,
Pubmed
Zhang,
Overexpression of stomatin depresses GLUT-1 glucose transporter activity.
2001,
Pubmed
Zhang,
Association of stomatin (band 7.2b) with Glut1 glucose transporter.
1999,
Pubmed
