Bardine N , Lamers G , Wacker S , Donow C , Knoechel W , Durston A .

	Figure 2. Mesodermal ectopic expression of a single Hox gene copies expression of the same Hox gene from mesoderm to neurectoderm.A– A’’’, E, F Localisation of mesoderm and neurectoderm in the wrap assay shown by expression of the mesodermal markers Chordin (Chd, A) and Brachyury (Bra, A’), and the neural marker Nrp1 (A”). In A’’’, lineage labelling by ectopic expression of GFP in the NOM only. These recombinants were analyzed 6 to 8 h after tissue healing. These data show that there is no tissue intermingling during wrap culture. Mesodermal Chd (expressed in SO, A) and GFP (within NOM, A’’’) do not mix with each other within the time course of wrap culture. Consistently, Bra, a pan mesodermal marker, is expressed in both types of mesoderm in accordance with its expression domain in the embryo (A’).The neural marker Nrp-1 is expressed in the space between mesoderm and the outermost ectodermal layer of the wrap, consistent with its known pattern of expression within the embryo (A’’). B–B’: Induction of Hoxd1 B: A wrap containing SO and NOM and ectoderm [AC(SO/NOM)AC] shows induction of Hoxd1 in the neurectoderm as well as mesoderm. B’, A wrap containing normal SO and SO ectopically expressing Hoxd1 also shows the induction of endogenous Hoxd1 in the neurectoderm as well as in the mesoderm. Endogenous Hoxd1 expression was detected using a 3′UTR probe that recognizes only the endogenous messenger. C, ectopic Hoxb4 in SO induces its own expression within the neurectoderm and in the mesoderm as in B’. D, wrap as in B’ and C but with ectopic Hoxc6 expression. This shows induction of Hoxc6 in neurectoderm and in the mesoderm. We used 3′UTR probes to detect expression of the endogenous mRNA’s in each of these experiments. E, F sections showing expression of Nrp1 (neural) and Bra (mesodermal) in control or standard [AC(SO/NOM)AC] recombinant. E Nrp1 expression is internal in the recombinant but excluded from an internal cell mass that is clearly the mesoderm. It is particularly strong around one end of the cell mass which is the neural inducing SO. Expression is also absent from the very outer layer of the recombinant, which represents the outer non neural layer of the neurectoderm. F: Bra expression is in an internal cell mass (the mesoderm). Please note that the germ layer markers Bra, Ch, and the mesodermal lineage label GFP are confined to an internal cell mass excluding tissue intermingling and that Hox expression is detected in neurectoderm as well as the mesodermal cell mass. Each photo in this figure represents at least 20 recombinants and embryos with consistently the same results.
	Figure 3. Hoxd1 homeoprotein containing a penetratin sequence is transferred from mesoderm to neurectoderm and its homeodomain plays a cargo function for gfp.A: Penetratin sequence is shown. Above, Hoxd1 homeodomain (HD) contains a penetratin like sequence (in red). This conserved sequence is a feature of all homeodoproteins. Below, two amino-acids WF within the penetratin were mutated into SR (highlighted by stars) to create a mutated Hoxd1 HD, mut HD. This mutation abrogates the transfer function of the HD. B–D”: Localisation of different fluorescent chimeric GFP proteins in recombinants after 6–8 hrs of culture. These proteins were introduced into wrap recombinates in SO. B: wild type GFP. C: wild type GFP coupled to wild type Hoxd1 homeodomain (d1-HD-gfp). D: the mutated homeodomain version coupled to wild type GFP (mut d1-HD-gfp).The signal has spread in d1-HD-gfp but not in wild type GFP or mut d1-HD-gfp. The GFP fluorescence is combined with phalloidin staining to increase its visibility. B, B’, B”: GFP expressed in the SO stays confined within the SO explant and fails to spread into surrounding neurectoderm. C, C’, C”: d1-HD-gfp spreads outside the mesodermal explant to the neurectoderm (spreading indicated by arrowheads). D, D’, D”: mut d1-HD-gfp protein shows a SO localisation pattern as shown by wild type GFP. Each photo in this figure is representative of 23 recombinates, each of which gave the same result. Homeoproteins contain a separate HD sequence regulating homeoprotein secretion as well as the penetratin sequence. The mutations we made were in the ‘penetratin’ uptake regulating sequence. Please note that d1-HD-GFP, mut d1-HD-GFP and GFP in Fig. 3 evidently diffuse less than Myc tagged Hoxd1 in S1 Figure. This is expected, due to the large size of GFP.
	Figure 4. Uptake of d1-HD-GFP and GFP by Drosophila imaginal wing discs.Drosphila imaginal wing discs were incubated with Hoxd1-HD-GFP (d1-HD-gfp) recombinant protein (B) or wild type GFP protein (A). or mutated mut-d1-HD-GFP. Recombinant d1-HD-gfp was taken up by the discs while wild type GFP and mut-d1-HD-GFP were not. Each photo in this figure represents 10 imaginal discs giving the same result. These data clearly show the cargo function of Hoxd1 homeodomain and suggest that this uptake is by a species independent mechanism.
	Figure 5. Craniofacial structures of Xenopus laevis tadpoles upon injection of Hoxd1 mRNA or protein.a: Schematic ventral view of an uninjected untreated control embryo. b: uninjected embryo. c: embryo injected with wild type GFP into the blastoecel at blastula stage. d: Embryo injected with Hoxd1 mRNA at 4 cell stage. e: Embryo injected with recombinant HOXD1 protein into 4 cell stage embryo. f: injection of recombinant HOXD1 protein into the blastoecel. Please note that standard injection of Hoxd1 mRNA or its protein counterpart injection in the cytoplasm or in the extracellular matrix leads to similar phenotypes in d, e and f. The embryos are strongly posteriorised as shown by the reduction (or deletion) of anterior structures. These data strongly suggest that the Hoxd1 protein successfully crossed the cellular membranes and retained its function as it leads to a severe truncation of anterior cartilage structures. Infrarostrale (in), Meckel’s cartilage (me), palatoquadrate (pa), ceratohyale (ce), basibranchiale (ba), branchial arches (br), eye (ey), intestine (in). Each photo represents 10 identically treated embryos giving the same result.
	Figure 1. Mesodermal Hox loss of function of a single Hox gene prevents neurectodermal Hox expression of the same Hox gene. Aa, Wrap assay consists of a piece of non-organiser mesoderm (NOM) and a piece of Spemann organiser mesoderm (SO) combined between two ectodermal animal caps. All tissues are excised from early gastrulae (st. 10a) Ab, Ba, Ca: External views of late gastrula stage Xenopus laevis expressing Hoxd1, Hoxb4 and Hoxb9 respectively. Note that the midline of the embryo, overlying the SO, does not express any Hox gene. Ac, Bb, Cb: wraps containing only SO explants [AC(SO/SO)AC]. Ad, Bc, Cc: wraps containing SO and NOM treated with control morpholino (ctMO) [AC(SO/NOM+ctMO)AC]. Ae, Bd, Cd, wrap with NOM treated with Hoxd1-, Hoxb4 and Hoxb9 MO’s respectively. Please note that in each case, only the wraps containing NOM and SO show Hox expression in the neurectoderm (Ad, Bc, Cc) and those containing only SO do not show any expression in accordance with the embryo’s lack of Hox expression in SO (Ab, Ba, Ca, and Ac, Bb, Cb). In each case, Hox MO treatment of NOM mesoderm also prevents the expression of the homologous Hox gene in neurectoderm (Ae, Bd, Cd). These wraps were fixed and analysed 6–8 hrs after they were made. Each photo of two recombinates or an embryo in this figure is representative of at least 20 recombinates or embryos, all showing the same result.

Bardine, Two Hoxc6 transcripts are differentially expressed and regulate primary neurogenesis in Xenopus laevis. 2009, Pubmed, Xenbase

Bardine, Two Hoxc6 transcripts are differentially expressed and regulate primary neurogenesis in Xenopus laevis. 2009, Pubmed , Xenbase
Bel-Vialar, Initiating Hox gene expression: in the early chick neural tube differential sensitivity to FGF and RA signaling subdivides the HoxB genes in two distinct groups. 2002, Pubmed , Xenbase
Brunet, The transcription factor Engrailed-2 guides retinal axons. 2005, Pubmed , Xenbase
Cao, The POU factor Oct-25 regulates the Xvent-2B gene and counteracts terminal differentiation in Xenopus embryos. 2004, Pubmed , Xenbase
Chatelin, Transcription factor hoxa-5 is taken up by cells in culture and conveyed to their nuclei. 1996, Pubmed
Chen, Planar signalling is not sufficient to generate a specific anterior/posterior neural pattern in pseudoexogastrula explants from Xenopus and Triturus. 2000, Pubmed , Xenbase
De Robertis, Dorsal-ventral patterning and neural induction in Xenopus embryos. 2004, Pubmed , Xenbase
Deschamps, Initiation, establishment and maintenance of Hox gene expression patterns in the mouse. 1999, Pubmed
Di Lullo, Paracrine Pax6 activity regulates oligodendrocyte precursor cell migration in the chick embryonic neural tube. 2011, Pubmed
Durston, Retinoic acid causes an anteroposterior transformation in the developing central nervous system. 1989, Pubmed , Xenbase
Fujii, Anteroposterior patterning in Xenopus embryos: egg fragment assay system reveals a synergy of dorsalizing and posteriorizing embryonic domains. 2002, Pubmed , Xenbase
Gavalas, Retinoid signalling and hindbrain patterning. 2000, Pubmed
Godsave, Graded retinoid responses in the developing hindbrain. 1998, Pubmed , Xenbase
Gould, Initiation of rhombomeric Hoxb4 expression requires induction by somites and a retinoid pathway. 1998, Pubmed , Xenbase
Grunz, The role of vertical and planar signals during the early steps of neural induction. 1995, Pubmed , Xenbase
Harland, Formation and function of Spemann's organizer. 1997, Pubmed
Jansen, The role of the Spemann organizer in anterior-posterior patterning of the trunk. 2007, Pubmed , Xenbase
Joliot, Transduction peptides: from technology to physiology. 2004, Pubmed
Joliot, Identification of a signal sequence necessary for the unconventional secretion of Engrailed homeoprotein. 1998, Pubmed
Joubin, Formation and maintenance of the organizer among the vertebrates. 2001, Pubmed
Kengaku, bFGF as a possible morphogen for the anteroposterior axis of the central nervous system in Xenopus. 1995, Pubmed , Xenbase
Kiecker, A morphogen gradient of Wnt/beta-catenin signalling regulates anteroposterior neural patterning in Xenopus. 2001, Pubmed , Xenbase
Kolm, Retinoids and posterior neural induction: a reevaluation of Nieuwkoop's two-step hypothesis. 1997, Pubmed
Layalle, Engrailed homeoprotein acts as a signaling molecule in the developing fly. 2011, Pubmed
Lloret-Vilaspasa, Retinoid signalling is required for information transfer from mesoderm to neuroectoderm during gastrulation. 2010, Pubmed , Xenbase
McNulty, Knockdown of the complete Hox paralogous group 1 leads to dramatic hindbrain and neural crest defects. 2005, Pubmed , Xenbase
Muhr, Assignment of early caudal identity to neural plate cells by a signal from caudal paraxial mesoderm. 1997, Pubmed
Pownall, eFGF, Xcad3 and Hox genes form a molecular pathway that establishes the anteroposterior axis in Xenopus. 1996, Pubmed , Xenbase
Poznanski, The role of planar and early vertical signaling in patterning the expression of Hoxb-1 in Xenopus. 1997, Pubmed , Xenbase
Ruiz i Altaba, Planar and vertical signals in the induction and patterning of the Xenopus nervous system. 1992, Pubmed , Xenbase
Schubert, A retinoic acid-Hox hierarchy controls both anterior/posterior patterning and neuronal specification in the developing central nervous system of the cephalochordate amphioxus. 2006, Pubmed
Spatazza, Choroid-plexus-derived Otx2 homeoprotein constrains adult cortical plasticity. 2013, Pubmed
Stern, Neural induction: old problem, new findings, yet more questions. 2005, Pubmed , Xenbase
Stern, Head-tail patterning of the vertebrate embryo: one, two or many unresolved problems? 2006, Pubmed
Sugiyama, Experience-dependent transfer of Otx2 homeoprotein into the visual cortex activates postnatal plasticity. 2008, Pubmed
Swindell, Complementary domains of retinoic acid production and degradation in the early chick embryo. 1999, Pubmed
Wacker, Timed interactions between the Hox expressing non-organiser mesoderm and the Spemann organiser generate positional information during vertebrate gastrulation. 2004, Pubmed , Xenbase
Wizenmann, Extracellular Engrailed participates in the topographic guidance of retinal axons in vivo. 2009, Pubmed , Xenbase
Woo, Specification of the zebrafish nervous system by nonaxial signals. 1997, Pubmed , Xenbase
