???displayArticle.abstract??? Fibroblast growth factor signaling plays a significant role in the developing eye, regulating both patterning and neurogenesis. Members of the Pea3/Etv4-subfamily of ETS-domain transcription factors (Etv1, Etv4, and Etv5) are transcriptional activators that are downstream targets of FGF/MAPK signaling, but whether they are required for eye development is unknown. We show that in the developing Xenopus laevis retina, etv1 is transiently expressed at the onset of retinal neurogenesis. We found that etv1 is not required for eye specification, but is required for the expression of atonal-related proneural bHLH transcription factors, and is also required for retinal neuron differentiation. Using transgenic reporters we show that the distalatoh7 enhancer, which is required for the initiation of atoh7 expression in the Xenopus retina, is responsive to both FGF signaling and etv1 expression. Thus, we conclude that Etv1 acts downstream of FGF signaling to regulate the initiation of neurogenesis in the Xenopus retina.
???displayArticle.pubmedLink???
24219979
???displayArticle.pmcLink???PMC3959783 ???displayArticle.link???Mech Dev ???displayArticle.grants???[+]
Fig. 1. Expression of etv1 in the developing Xenopus laevis eye. Etv1 is detected by whole mount in situ hybridization during optic vesicle evagination (A, anterior view – bracket; inset, lateral view – arrow), in the pre-neurogenic optic vesicle (B, anterior view – bracket; inset, lateral view – arrow), and during the initial stages of retinal neurogenesis, (C and D, lateral view). By stage 29–30, etv1 is only expressed in the developing lens vesicle (E, lateral view – arrowhead). In situ hybridization on sections shows etv1 is most highly expressed in the ventral stalk and ventral optic vesicle at stage 24, with weaker expression in the neuroepithelium of the central to dorsal optic vesicle, and overlying surface ectoderm (F). At stage 28, etv1 is expressed throughout the retinal neuroepithelium and overlying surface ectoderm (G). At stage 29–30, the developing lens vesicle is strongly labeled, while there is no detectable expression of etv1 in the developing neural retina (H). At the end of embryonic retinal neurogenesis, etv1 is expressed in the photoreceptors of the outer nuclear layer but is absent from the rest of the central retina and also from progenitors in the ciliary marginal zone (I). Abbreviations: ov, optic vesicle; e, eye; lv, lens vesicle; se, surface ectoderm; ne, neuroepithelium; os, optic stalk; nr, neural retina; cmz, ciliary marginal zone; onl, outer nuclear layer.
Fig. 2.
Loss of Etv1 function prevents proneural gene expression. Etv1 function was blocked by injection of etv1 MO at the 8-cell stage (B,E,H,K,N,Q,T) or by transgenic expression of dnEtv1 using the eye-specific enhancer for human fzd5 (C,F,I,L,O,R,U). In situ hybridization on stage 28 embryos showed that expression of early retinal markers were unaffected relative to the uninjected side, including rax (A and B, n = 78/82 unaffected; C, n = 32/32), pax6 (D and E, n = 59/65; F, n = 15/15), sox2 (G and H, n = 51/58; I, n = 28/28), and the pre-neurogenesis bHLH gene ascl3 (J and K n = 37/37; L, n = 32/32). Expression of proneural bHLH genes required for retinal neurogenesis was reduced compared to the uninjected side: atoh7 (M and N, n = 70/124 reduced; O, n = 56/98), neurog2 (P and Q, n = 39/61; R, n = 20/34), and neurod1 (S and T, n = 53/103; U, n = 18/28). Arrows indicate the eye.
Fig. 5.
Etv1 overexpression does not trigger early retinal neurogenesis. Early retinal patterning genes rax (A–C) and pax6 (D–F) were unaffected by 8-cell injection of mRNA for etv1. The proneural bHLH gene atoh7 (G, n = 49) and neurod1 (J, n = 76) were not expressed prematurely at stage22/23, indicating that etv1 was insufficient to initiate their expression. At stage 28, expression of both atoh7 (H and I) and neurod1 (K and L) was reduced on the injected side compared to the uninjected side (n = 24/48 for atoh7; n = 20/34 for neurod1). Arrows indicate the eye.
Agathocleous,
A directional Wnt/beta-catenin-Sox2-proneural pathway regulates the transition from proliferation to differentiation in the Xenopus retina.
2009, Pubmed,
Xenbase
Agathocleous,
A directional Wnt/beta-catenin-Sox2-proneural pathway regulates the transition from proliferation to differentiation in the Xenopus retina.
2009,
Pubmed
,
Xenbase
Aldiri,
Polycomb repressive complex PRC2 regulates Xenopus retina development downstream of Wnt/β-catenin signaling.
2013,
Pubmed
,
Xenbase
Amaya,
Expression of a dominant negative mutant of the FGF receptor disrupts mesoderm formation in Xenopus embryos.
1991,
Pubmed
,
Xenbase
Atkinson-Leadbeater,
FGF receptor dependent regulation of Lhx9 expression in the developing nervous system.
2009,
Pubmed
,
Xenbase
Bassett,
Cell fate determination in the vertebrate retina.
2012,
Pubmed
Bosc,
Regulation of Her2/neu promoter activity by the ETS transcription factor, ER81.
2002,
Pubmed
Brent,
FGF acts directly on the somitic tendon progenitors through the Ets transcription factors Pea3 and Erm to regulate scleraxis expression.
2004,
Pubmed
Brown,
Specificities of protein-protein and protein-DNA interaction of GABP alpha and two newly defined ets-related proteins.
1992,
Pubmed
Cai,
Temporal requirement of the protein tyrosine phosphatase Shp2 in establishing the neuronal fate in early retinal development.
2010,
Pubmed
Cai,
Deficient FGF signaling causes optic nerve dysgenesis and ocular coloboma.
2013,
Pubmed
Campochiaro,
Retinal degeneration in transgenic mice with photoreceptor-specific expression of a dominant-negative fibroblast growth factor receptor.
1996,
Pubmed
Chen,
Characterization of the Ets-type protein ER81 in Xenopus embryos.
1999,
Pubmed
,
Xenbase
Chow,
Pax6 induces ectopic eyes in a vertebrate.
1999,
Pubmed
,
Xenbase
de Launoit,
The Ets transcription factors of the PEA3 group: transcriptional regulators in metastasis.
2006,
Pubmed
Fontaine,
Survival of purified rat photoreceptors in vitro is stimulated directly by fibroblast growth factor-2.
1998,
Pubmed
Friesel,
Spatially restricted expression of fibroblast growth factor receptor-2 during Xenopus development.
1992,
Pubmed
,
Xenbase
Fuhrmann,
Eye morphogenesis and patterning of the optic vesicle.
2010,
Pubmed
Graves,
Specificity within the ets family of transcription factors.
1998,
Pubmed
Green,
Two animal models of retinal degeneration are rescued by recombinant adeno-associated virus-mediated production of FGF-5 and FGF-18.
2001,
Pubmed
Guillemot,
Retinal fate and ganglion cell differentiation are potentiated by acidic FGF in an in vitro assay of early retinal development.
1992,
Pubmed
Harris,
Molecular recapitulation: the growth of the vertebrate retina.
1998,
Pubmed
Hirsch,
Xenopus Pax-6 and retinal development.
1997,
Pubmed
,
Xenbase
Hochmann,
Fgf signaling is required for photoreceptor maintenance in the adult zebrafish retina.
2012,
Pubmed
Huang,
The retinal fate of Xenopus cleavage stage progenitors is dependent upon blastomere position and competence: studies of normal and regulated clones.
1993,
Pubmed
,
Xenbase
Hutcheson,
Transgenic approaches to retinal development and function in Xenopus laevis.
2002,
Pubmed
,
Xenbase
Kanekar,
Xath5 participates in a network of bHLH genes in the developing Xenopus retina.
1997,
Pubmed
,
Xenbase
Kinkl,
Alternate FGF2-ERK1/2 signaling pathways in retinal photoreceptor and glial cells in vitro.
2001,
Pubmed
Kroll,
Transgenic Xenopus embryos from sperm nuclear transplantations reveal FGF signaling requirements during gastrulation.
1996,
Pubmed
,
Xenbase
Lee,
Conversion of Xenopus ectoderm into neurons by NeuroD, a basic helix-loop-helix protein.
1995,
Pubmed
,
Xenbase
Locker,
Stemness or not stemness? Current status and perspectives of adult retinal stem cells.
2009,
Pubmed
Lupo,
Dorsoventral patterning of the Xenopus eye: a collaboration of Retinoid, Hedgehog and FGF receptor signaling.
2005,
Pubmed
,
Xenbase
Ma,
Identification of neurogenin, a vertebrate neuronal determination gene.
1996,
Pubmed
,
Xenbase
Maroulakou,
Expression and function of Ets transcription factors in mammalian development: a regulatory network.
2000,
Pubmed
Martinez-Morales,
Differentiation of the vertebrate retina is coordinated by an FGF signaling center.
2005,
Pubmed
Mathers,
The Rx homeobox gene is essential for vertebrate eye development.
1997,
Pubmed
,
Xenbase
McCabe,
The development of the pattern of retinal ganglion cells in the chick retina: mechanisms that control differentiation.
1999,
Pubmed
McCabe,
Pea3 expression is regulated by FGF signaling in developing retina.
2006,
Pubmed
McFarlane,
FGF signaling and target recognition in the developing Xenopus visual system.
1995,
Pubmed
,
Xenbase
McFarlane,
A role for the fibroblast growth factor receptor in cell fate decisions in the developing vertebrate retina.
1998,
Pubmed
,
Xenbase
Mizuseki,
Xenopus Zic-related-1 and Sox-2, two factors induced by chordin, have distinct activities in the initiation of neural induction.
1998,
Pubmed
,
Xenbase
Moody,
Fates of the blastomeres of the 32-cell-stage Xenopus embryo.
1987,
Pubmed
,
Xenbase
Moody,
Fates of the blastomeres of the 16-cell stage Xenopus embryo.
1987,
Pubmed
,
Xenbase
Moore,
Posttranslational mechanisms control the timing of bHLH function and regulate retinal cell fate.
2002,
Pubmed
,
Xenbase
Münchberg,
The Xenopus Ets transcription factor XER81 is a target of the FGF signaling pathway.
1999,
Pubmed
,
Xenbase
Nakayama,
Fgf19 is required for zebrafish lens and retina development.
2008,
Pubmed
Park,
Basic fibroblast growth factor induces retinal regeneration in vivo.
1989,
Pubmed
Patel,
Overexpression of FGF-2 alters cell fate specification in the developing retina of Xenopus laevis.
2000,
Pubmed
,
Xenbase
Perron,
The genetic sequence of retinal development in the ciliary margin of the Xenopus eye.
1998,
Pubmed
,
Xenbase
Picker,
Dynamic coupling of pattern formation and morphogenesis in the developing vertebrate retina.
2009,
Pubmed
Picker,
Fgf signals from a novel signaling center determine axial patterning of the prospective neural retina.
2005,
Pubmed
Pottin,
Restoring eye size in Astyanax mexicanus blind cavefish embryos through modulation of the Shh and Fgf8 forebrain organising centres.
2011,
Pubmed
Qin,
FGF signaling regulates rod photoreceptor cell maintenance and regeneration in zebrafish.
2011,
Pubmed
Remy,
The Ets-transcription factor family in embryonic development: lessons from the amphibian and bird.
2000,
Pubmed
,
Xenbase
Riesenberg,
Pax6 regulation of Math5 during mouse retinal neurogenesis.
2009,
Pubmed
,
Xenbase
Riou,
Early regionalized expression of a novel Xenopus fibroblast growth factor receptor in neuroepithelium.
1996,
Pubmed
,
Xenbase
Robinson,
An essential role for FGF receptor signaling in lens development.
2006,
Pubmed
Shaham,
Pax6: a multi-level regulator of ocular development.
2012,
Pubmed
Shiozaki,
Cloning of cDNA and genomic DNA encoding fibroblast growth factor receptor-4 of Xenopus laevis.
1995,
Pubmed
,
Xenbase
Sievers,
Fibroblast growth factors promote the survival of adult rat retinal ganglion cells after transection of the optic nerve.
1987,
Pubmed
Siffroi-Fernandez,
FGF19 exhibits neuroprotective effects on adult mammalian photoreceptors in vitro.
2008,
Pubmed
Sinn,
An eye on eye development.
2013,
Pubmed
Song,
Spatial and temporal expression of basic fibroblast growth factor (FGF-2) mRNA and protein in early Xenopus development.
1994,
Pubmed
,
Xenbase
Spence,
Retina regeneration in the chick embryo is not induced by spontaneous Mitf downregulation but requires FGF/FGFR/MEK/Erk dependent upregulation of Pax6.
2007,
Pubmed
Take-uchi,
Hedgehog signalling maintains the optic stalk-retinal interface through the regulation of Vax gene activity.
2003,
Pubmed
,
Xenbase
Tannahill,
Developmental expression of the Xenopus int-2 (FGF-3) gene: activation by mesodermal and neural induction.
1992,
Pubmed
,
Xenbase
Tuoc,
Er81 is a downstream target of Pax6 in cortical progenitors.
2008,
Pubmed
Turner,
Expression of achaete-scute homolog 3 in Xenopus embryos converts ectodermal cells to a neural fate.
1994,
Pubmed
,
Xenbase
Van Raay,
Frizzled 5 signaling governs the neural potential of progenitors in the developing Xenopus retina.
2005,
Pubmed
,
Xenbase
Vergara,
Retinal regeneration in the Xenopus laevis tadpole: a new model system.
2009,
Pubmed
,
Xenbase
Vinothkumar,
Sequential and cooperative action of Fgfs and Shh in the zebrafish retina.
2008,
Pubmed
Willardsen,
Temporal regulation of Ath5 gene expression during eye development.
2009,
Pubmed
,
Xenbase
Yoshii,
Neural retinal regeneration in the anuran amphibian Xenopus laevis post-metamorphosis: transdifferentiation of retinal pigmented epithelium regenerates the neural retina.
2007,
Pubmed
,
Xenbase
Zhao,
Patterning the optic neuroepithelium by FGF signaling and Ras activation.
2001,
Pubmed
