Xenbase Image ID: 1359

Figure 3. Spatial expression pattern of Xmad1, Xmad3, and Xmnt in Xenopus embryos. (A-I) Xmad1, (J-P) Xmad3, and (Q-W) Xmnt. (A) Stage 6.5 lat., (B) stage 10 veg., (C) stage 11 veg., (D) stage 13 d., (E) stage 17 ant., (F) stage 17, transversal section, (G) stage 19, (H) stage 27, (I) stage 27, transversal section, (J) stage 20 d., (K) stage 20 lat., (L) stage 23 ant., (M) stage 23 d., (N) stage 29, (O) transversal section S1 of N, (P) transversal section S2 of N, (Q) stage 19 ant., (R) stage 19 d., (S) stage 20 lat., (T) stage 23 lat., (U) stage 27, (V) stage 27 sagittal section S1, and (W) stage 27 transversal section S2. anp, anterior neural plate; b, branchial crest segment; cg, cement gland; d, dorsal; ev, eye vesicle; fb, forebrain; fp, floor plate; h, hyoid crest segment; hb, hindbrain; hc, hypochord; lat, lateral; mz marginal zone; nc, notochord; nt, neural tube; veg, vegetal; mb, midbrain; op, olfactory placode; otic vesicle; P, pronephros; pg, pineal gland; sc, spinal chord; r, retina; V, trigeminal ganglion; VII, geniculate ganglion. The dashed line indicates the plane of the section. Image published in: Juergens K et al. (2005) Copyright © 2005. Image reproduced with permission of the Publisher, John Wiley & Sons. Gene Synonyms Species Stage(s) Tissue mxd1.L xmad1 X. laevis Throughout NF stage 10 dorso-lateral marginal zone mxd1.L xmad1 X. laevis Throughout NF stage 11 dorsal marginal zone mxd1.L xmad1 X. laevis Throughout NF stage 13 neural groove neuroectoderm mnt.L rox, xmnt X. laevis Throughout NF stage 13 to NF stage 21 neural crest pre-chordal neural plate spinal cord mxd1.L xmad1 X. laevis Throughout NF stage 17 floor plate neural tube notochord mxd1.L xmad1 X. laevis Throughout NF stage 17 neural groove cement gland primordium notochord axial mesoderm mxd1.L xmad1 X. laevis Throughout NF stage 19 cement gland notochord spinal cord floor plate mnt.L rox, xmnt X. laevis Sometime during NF stage 19 to NF stage 23 central nervous system optic vesicle hyoid crest branchial crest cement gland primordium mxd3.L Mad3, xmad3 X. laevis Throughout NF stage 20 eye primordium mnt.L rox, xmnt X. laevis Throughout NF stage 27 retina spinal cord forebrain midbrain hindbrain mxd1.L xmad1 X. laevis Throughout NF stage 27 cement gland notochord cranial placode neurogenic placode trigeminal placode facial nerve trigeminal nerve spinal cord floor plate olfactory placode mxd3.L Mad3, xmad3 X. laevis Throughout NF stage 27 neural tube olfactory placode hindbrain midbrain mxd1.L xmad1 X. laevis Throughout NF stage 6.5 animal hemisphere Image source: Published Larger Image Printer Friendly View
